| Engine model | ISDe185 |
| Engine type | 4 stroke, 6 cylinders in line |
| Displacement | 6.7 L |
| Rated Power | 136kW (185 HP) @ 2500rpm |
| Peak Torque | 700N.m @ 1200-1700rpm |
| Emission Standard | Euro Ⅲ |
| Aftertreatment | CES Standand |
Cummins engine ISDe185 technique specification |
|
|---|---|
| Bore*stroke | 107 * 124mm |
| Intake method | Turbochager & Intercooled |
| Fuel systeme | Bosch Pump |
| Cooling method | Fluid Cooling 7.4 L |
| Governor Type | Electronic Control |
| Compression Ratio | 17.3 : 1 |
| Fuel Consumption | 224 g/kW.h |
| Starting System | Electrical Starting Motor 24V/750A,12V/500A |
| Lowest Starting Temp .(with/without auxiliary system) | -10℃/-25℃ |
Cummins diesel engine ISDe185 trade parameters |
|
| Warranty time | 1year or 1500h |
| Engine Size(L*W*H): | 940mm*742mm*837mm |
| Packing size | 980mm*850mm*890mm |
| Weight net | 420 Kg |
| Weight gross | 519 Kg |
| Delivary port | Shanghai |
| Marine delivary boat | Masket/zhongyuan |
| Trade termes | FOB/CIF/EXW |
| Delivary time | 15 working days |
| Payement termes | T/T，L/C |
| Mode of transport | Sea transportation or air transportation |
Using Genuine Cummins parts makes all the difference. Genuine Cummins new and ReCon® parts are guaranteed to fit right and work right.
Extend the life of your equipment by choosing the best parts for your Cummins engine or generator.
Backed by Cummins with a 100% comprehensive warranty on parts, labour and progressive damage nothing works better or lasts longer.
The difference between Genuine Cummins parts and non-genuine parts isn’t always the easiest to detect.
Precision design, state-of-the-art manufacturing and rigorous testing ensures that Genuine Cummins parts perform at Cummins factory-specified levels of durability, reliability and performance.
Don't see the parts you are looking for? Click Here and we can get it for you or send you a quote from the thousands of commonly used Cummins parts.
