C/N | Description | Part-Number | Qty |
---|---|---|---|
01 | GEAR CASE | 5500101433 | 00 |
02 | O-RING | 700429260000 | 12 |
03 | SCREW | 000912008063 | 48 |
04 | WASHER | 000433008403 | 48 |
05 | CYLINDER HEAD COVER | 5500100330 | 12 |
06 | GASKET | 5500160121 | 12 |
C/N | New Part Number | Superseded Part Number | Valid From Date |
---|---|---|---|
01 | X87305500002 | 5500100330 | N/A |
02 | X87305500002 | 5370100030 | 2009/12/01 |
03 | X87305500002 | 5500100030 | 2010/01/01 |
04 | X87305500002 | 5500100230 | 2010/02/01 |
05 | X87305500002 | X87305500002 | 2010/03/01 |
Make | Year of construction | Power KW | U/MIN |
---|---|---|---|
12V 396 TC54 | N/A | 1125 | 1800 |
12V 396 TC54 | N/A | 1310 | 1800 |
12V 396 TC64 | N/A | 960 | 1600 |
12V 396 TE64 | N/A | 1020 | 1600 |
12V 396 TE74 | N/A | 1500 | 1900 |
12V 396 TE74L | N/A | 1500 | 1900 |
12V 396 TE74L | N/A | 1500 | 1800 |
12V 396 TE84 | N/A | 1500 | 1900 |
12V 396 TE94 | N/A | 1680 | 2000 |
12V 396 TB94 | N/A | 1920 | 2100 |
