C/N | Description | Part-Number | Qty |
---|---|---|---|
000 | 2/2-WAY SOLENOID VALVE | 5840900595 | 001 |
01 | VALVE HOUSING | 5840900054 | 001 |
02 | 2/2-WAY SOLENOID VALVE | 5840980257 | 001 |
03 | PRESSURE SPRING | 5849931601 | 001 |
04 | PUMP TIMING PISTON | 5840982719 | 001 |
05 | GASKET | 0000981465 | 001 |
06 | GASKET | 0000981565 | 001 |
07 | HEX NUT | 206925008000 | 001 |
08 | SEALING RING | 007603033100 | 001 |
09 | SCREW-FITTING UNION | 5849970572 | 001 |
Make | Year of construction | Power KW | U/MIN |
---|---|---|---|
16V 1163 TB73L | N/A | 5200 | 1230 |
20V 1163 TB73 | N/A | 6000 | 1200 |
20V 1163 TB73L | N/A | 6500 | 1230 |
12V 1163 TB93 | N/A | 4440 | 1900 |
16V 1163 TB93 | N/A | 5920 | 1900 |
20V 1163 TB93 | N/A | 7400 | 1900 |
16V 1163 TB76 | N/A | 4320 | 1200 |
16V 1163 TB76L | N/A | 4800 | 1200 |
16V 1163 TB82 | N/A | 3580 | 1200 |
20V 1163 TB82 | N/A | 4480 | 1200 |
