MTU 5800162319 Technical Engineering Exploded View

MTU 5800162319 Technical Engineering Exploded View

MTU 5800162319 Technical Engineering Exploded View

C/N Description Part-Number Qty
55 CYLINDER HEAD W/VALVES 5840102120 020
65 SCREW 5840160271 020
75 THREADED PLUG 000910022003 030
80 SEALING RING 5800980565 030
85 PLUG 5840980171 030
90 SEALING RING 5800980465 030
95 SEALING RING 5800110259 030
105 STRESS BOLT 5809900819 160
110 THRUST WASHER 5800160062 160
120 SLEEVE 135A45008/2 140
125 SEALING RING 5610110059 140
135 SEAL CARRIER 5800110258 040
140 SEALING RING 5800110259 040
145 O-RING 700429050000 040
155 SEALING RING 5800162319 020
165 SEALING RING SIZE 1 5800162419 001
170 SEALING RING SIZE 2 5800162519 001
180 SEAL CARRIER 5800110558 020
185 SEALING RING 5809970048 160

5800162319 SUPERSEDED PART AND EFFECTIVE DATE

5800162319 SUPERSEDED PART AND EFFECTIVE DATE

C/N New Part Number Superseded Part Number Valid From Date
01 5800162319 5800161319 N/A
02 5800162319 5800161919 1998/06/01
03 5800162319 5800162319 1998/07/01

MTU 1163 Diesel Engine Models & Specifications

MTU 20V 1163 Diesel Engine

MTU 1163 Diesel Engine Models & Specifications

Make Year of construction Power KW U/MIN
16V 1163 TB73L N/A 5200 1230
20V 1163 TB73 N/A 6000 1200
20V 1163 TB73L N/A 6500 1230
12V 1163 TB93 N/A 4440 1900
16V 1163 TB93 N/A 5920 1900
20V 1163 TB93 N/A 7400 1900
16V 1163 TB76 N/A 4320 1200
16V 1163 TB76L N/A 4800 1200
16V 1163 TB82 N/A 3580 1200
20V 1163 TB82 N/A 4480 1200
