C/N | Description | Part-Number | Qty |
---|---|---|---|
01 | CABLE GLAND | 000N33089/1 | 001 |
02 | WASHER | 000N33090/1 | 001 |
03 | NOZZLE ELEMENT | 000N33726/1 | 001 |
04 | NOZZLE CAP | 000N33105/1 | 001 |
05 | 2/2-WAY SOLENOID VALVE | 000N33714/1 | 001 |
11 | STROKE LIMITER | 000N33108/1 | 001 |
12 | VALVE SPRING | 000N33109/1 | 001 |
13 | DELIVERY VALVE | 000N33715/1 | 001 |
16 | HELICAL GEAR | 000N33048/1 | 001 |
17 | CLAMPING RING | 000N33064/1 | 001 |
18 | LIFTING-EYE NUT | 000N33065/1 | 001 |
C/N | New Part Number | Superseded Part Number | Valid From Date |
---|---|---|---|
01 | 000N33715/1 | 000N33715/2 | N/A |
02 | 000N33715/1 | 000N33747/1 | 1997/12/01 |
03 | 000N33715/1 | 000N33715/1 | 1998/01/01 |
Make | Year of construction | Power KW | U/MIN |
---|---|---|---|
12V 538 TB92 | N/A | 2250 | 1900 |
20V 538 TB92 | N/A | 3000 | 1900 |
16V 538 TB93 | N/A | 3300 | 1900 |
20V 538 TB93 | N/A | 4120 | 1900 |
12V 538 TB8 | MD 656 | 1655 | 1800 |
12V 538 TB9 | MD 657 | 1986 | 1900 |
20V 538 TB1 | MD 1080 | 2096 | 1600 |
20V 538 TB6 | MD 1080 | 1839 | 1500 |
20V 538 TB7 | MC 1080/30 | 2390 | 1720 |
16V 538 TB9 | MD 872 | 2648 | 1900 |
