C/N | Description | Part-Number | Qty |
---|---|---|---|
01 | RAW WATER PUMP | 5622001101 | 001 |
02 | GASKET | 5602011080 | 001 |
02A | GASKET | 5602011180 | 001 |
02B | GASKET | 5602011280 | 001 |
02C | GASKET | 5602011380 | 001 |
03 | SCREW | 000931012198 | 004 |
04 | SCREW | 000931012176 | 002 |
05 | SPRING WASHER | 000137012202 | 007 |
06 | COOLANT INLET NECK | 137L36702/2 | 001 |
07 | INTERMEDIATE MEMBER | 5612010230 | 001 |
08 | GASKET | 5602011480 | 002 |
09 | SCREW | 000931010336 | 002 |
10 | SCREW | 000933010150 | 004 |
11 | SPRING WASHER | 000137010202 | 013 |
12 | EXHAUST PIPE NECK | 135L37702/2 | 002 |
13 | GASKET | 5602030380 | 002 |
14 | SCREW | 000931010332 | 002 |
15 | SCREW | 000933010094 | 004 |
17 | PLUG | 000910016003 | 002 |
18 | SEALING RING | 007603016105 | 002 |
19 | SPACER FLANGE | 5622000046 | 002 |
20 | GASKET | 5602030580 | 002 |
21 | SPRING WASHER | 000137008203 | 006 |
22 | SCREW | 304017008083 | 006 |
23 | SEALING RING | 007603030101 | 002 |
24 | PLUG | 000910030000 | 002 |
C/N | New Part Number | Superseded Part Number | Valid From Date |
---|---|---|---|
01 | 5602011480 | 135L35016/1 | N/A |
02 | 5602011480 | 135L35016/3 | 1995/10/01 |
03 | 5602011480 | 5602011480 | 1995/11/01 |
Make | Year of construction | Power KW | U/MIN |
---|---|---|---|
12V 538 TB92 | N/A | 2250 | 1900 |
20V 538 TB92 | N/A | 3000 | 1900 |
16V 538 TB93 | N/A | 3300 | 1900 |
20V 538 TB93 | N/A | 4120 | 1900 |
12V 538 TB8 | MD 656 | 1655 | 1800 |
12V 538 TB9 | MD 657 | 1986 | 1900 |
20V 538 TB1 | MD 1080 | 2096 | 1600 |
20V 538 TB6 | MD 1080 | 1839 | 1500 |
20V 538 TB7 | MC 1080/30 | 2390 | 1720 |
16V 538 TB9 | MD 872 | 2648 | 1900 |
