C/N | Description | Part-Number | Qty |
---|---|---|---|
50 | BEARING HOUSING FOR SEAWATER PUMP | X59420700004 | 001 |
100 | CYL. ROLLER BEARING | 205412422005 | 001 |
150 | RING SNAP | 000472080000 | 001 |
200 | BUSHING | X59420700009 | 001 |
250 | BEARING ANGULAR CONT ACT ROLLER | 200628103006 | 001 |
300 | SHAFT WAT PUMP HT CO OLING CIRCUT | 5272010505 | 001 |
350 | SEAL CARRIER FOR SEAWATER PUMP | X59620700004 | 001 |
400 | O-RING | 700429135000 | 001 |
450 | SEAL OIL 48 X 72 X 8 MNN386 | 700386048001 | 001 |
500 | O-RING | 700429190001 | 001 |
550 | IMPELLER FOR SEAWATER PUMP | X00037017 | 001 |
600 | WASHER | 000125008427 | 004 |
650 | HEX SCREW | 000000004389 | 004 |
700 | SPIRAL HOUSING FOR SEAWATER PUMP | X59620700001 | 001 |
750 | GEAR | X00041743 | 001 |
800 | WASHER | 200433013000 | 006 |
850 | HEX SCREW | 000000000905 | 002 |
900 | HEX SCREW | 304017012018 | 004 |
950 | COPPER SEALING RING | 007603038101 | 001 |
1000 | PLUG | 000908038003 | 001 |
1050 | PLUG | 735210014001 | 002 |
1100 | ROTARY SEAL | X52420200075 | 001 |
1150 | PLUG | X52499100658 | 002 |
C/N | New Part Number | Superseded Part Number | Valid From Date |
---|---|---|---|
01 | X52420200075 | XP59420700039 | N/A |
02 | X52420200075 | X52420200075 | 2014/01/01 |
Make | Rated power kW | Speed rpm | Bore/stroke mm (in) |
---|---|---|---|
8V 4000 M63 | 1000 | 1800 | 170/210 (6.7/8.3) |
12V 4000 M63 | 1500 | 1800 | 170/210 (6.7/8.3) |
12V 4000 M65L | 1680 | 1800 | 170/210 (6.7/8.3) |
16V 4000 M63L | 2240 | 1800 | 170/210 (6.7/8.3) |
16V 4000 M65L | 2240 | 1800 | 170/210 (6.7/8.3) |
8V 4000 M54R | 746 | 1600 | 170/210 (6.7/8.3) |
8V 4000 M55RN | 746 | 1600 | 170/210 (6.7/8.3) |
8V 4000 M54 | 895 | 1800 | 170/210 (6.7/8.3) |
8V 4000 M53 | 950 | 1800 | 170/210 (6.7/8.3) |
12V 4000 M55R | 1119 | 1600 | 170/210 (6.7/8.3) |
12V 4000 M53R | 1140 | 1600 | 170/210 (6.7/8.3) |
12V 4000 M54 | 1193 | 1800 | 170/210 (6.7/8.3) |
12V 4000 M64 | 1398 | 1800 | 130/150 (5.1/5.9) |
12V 4000 M93 | 2340 | 2100 | 165/190 (6.5/7.5) |
12V 4000 M73L | 2160 | 2050 | 170/210 (6.7/8.3) |
16V 4000 M73 | 2560 | 1970 | 170/210 (6.7/8.3) |
12V 4000 M93L | 2580 | 2100 | 170/210 (6.7/8.3) |
20V 4000 M65L | 2800 | 1800 | 170/210 (6.7/8.3) |
