X59301300049 CYLINDER LINER STAGE 0

Other
Other XP00A36400005 FILTER ELEMENT X52407800004 FLOW RESTRICT VALVE 0299976748 O-RING X52499100774 SUPPORT PLATE X52420200075 ROTARY SEAL X51699100327 SHAFT SEAL RING XP59420700027 IMPELLER 5272010153 SPACER SLEEVE X59407700014 ADAPTER 23540455 CENTRIFUGAL OIL FILTER ASM X00040012 SPEED SENSOR 5110251976 WASHER X59610100061 BEARING BODY X59610100101 THRUST BEARING 8695860572 GASKET KIT XP59420300091 SEAL RING 5241870380 GASKET X52414100132 GASKET FOR EXHAUST PIPE X56912300043 ACTUATING CYLINDER X59420200235 RESTRICTOR X59420200234 RESTRICTOR X59420200233 RESTRICTOR X59420200238 RESTRICTOR 5240384110 CONROD BEARING UPPER HALF XP58420400009 GASKET X00041552 COOLER PLATE X52403800001 CONROD BEARING XP52618300032 OIL FILTER ELEMENT X00008369 PISTON 5410180233 DIAPHRAGM 700429038003 O-RING XP59307500002 O-RING X52405500190 PROFILE GASKET F CYLIND EX59403700072 PISTON X59403800071/42 CONNECTING ROD 5241420780 GASKET 23540304/A1 GASKET KIT 5240384210 CONROD BEARING SIZE 0-1 X00043219 CONROD BEARING SIZE 0-1 5240332730 CRANKSHAFT BEARING DRIVING X00016599 BEARING BUSHING X59301300049 CYLINDER LINER STAGE 0 XP59501800123 FILTER ELEMENT 5260200305 HOUSING+ROTATING ASM EX00008371 PISTON X00E50201372 TEMPERATURE SENSOR X52404500056 SPARKPLUG X00E50200176 CONNECTION INTERFACE 0001424957 RING EXH MANIF X52408300025 FUEL HAND PUMP 5240980281 HOSE X00044065 SLEEVE RUBBER X52420300037 THERMAL ACTUATOR 5240333407 BEARING THRUST/0-1/LO/SPT 5240332608 BEARING THRUST/0-1/UP/RIL 5110850960 PISTON RING X52499100815 4/2-WAY SOL. VALVE XP52712100006 FILTER ELEMENT XP52712100005 FILTER ELEMENT XP52712100003 FILTER ELEMENT XP52712100002 FILTER ELEMENT 5205304069 SPEED TRANSMITTER X52421300004 ALTERNATOR 0219976547 SEAL RING CRANKSHAFT FRONT 0219976647 SEAL RING CRANKSHAFT REAR 5240114210 CYLINDER LINER SIZE 0 XP59408300054 FILTER CARTRIDGE XP59400600004 GASKET KIT XP52718300064 GASKET KIT XP52718300065 CIRCLIP KIT XP52718300060 PAPER INSERT X52808100004 FUEL DELIVERY PUMP 8691840027 ROTOR COMPLETE 5240530905 EXHAUST VALVE 5240531101 INLET VALVE 5240550550 BUSHING X52499100259 ADJUSTING SCREW X52405400013 PUSHROD 0000530926 VALVE KEEPER WEDGE 5240530120 VALVE SPRING OUTER 5240530122 VALVE SPRING INNER 5240530805 EXHAUST VALVE X52404100226 INLET VALVE X52404200037 GASKET FOR CYLINDER HEAD X52404200052 SEAL RING 5240380471 CONROD BOLT 0120373618 OIL CONTROL RING 0090375019 TAPER FACE COMP RING X00009806 RECTANGLR-SECT RING 5240336702 CRANKSHAFT BEARING SIZE 0-1 X52403100003 CRANKSHAFT BEARING SIZE 0-1 5240336602 CRANKSHAFT BEARING LOWER HALF X00016024 CRANKSHAFT BEARING SIZE 0-0 5240332630 CRANKSHAFT BEARING AUX PTO END 5240111380 GASKET X00027830 CYLINDER LINER SIZE 0 C23 5240510110 BEARING CAMSHAFT STD
PART NUMBER X59301300049
ENGINE TYPE MTU 4000 GAS ENGINE
DESCRIPTION CYLINDER LINER STAGE 0
DIMENSIONS BR 4000 GAS L64
UNIT WEIGHT 17.120 KG
HS CODE 84099900
NATO-VERS.-NR. N/A
MTU Friedrichshafen GmbH
MTU Friedrichshafen GmbH
  • Install drawings
  • original parts

MTU X59301300049 Technical Engineering Exploded View

MTU X59301300049 Technical Engineering Exploded View

MTU X59301300049 Technical Engineering Exploded View

C/N Description Part-Number Qty
20 CRANKCASE FOR 8V X52901100045 0001
30 CRANKSHAFT BRG CAP X52901100008 005
40 STUD F/CRANKSHFT BEARING X54701100013 010
50 COLLAR NUT X54701100010 010
60 SCREW W. INTERNAL HEX. X52999100023 020
70 SEALING CAP 5249970020 016
80 BEARING CAMSHAFT STD 5240510110 005
90 BUSHING X52901100019 002
110 CYLINDER LINER STAGE 0 X59301300049 008
130 SEALING RING 5550110259 016
150 O-RING X54799100238 008

X59301300049 SUPERSEDED PART AND EFFECTIVE DATE

X59301300049 SUPERSEDED PART AND EFFECTIVE DATE

C/N New Part Number Superseded Part Number Valid From Date
01 X59301300049 X59301300042 N/A
02 X59301300049 X52601300008 2016/12/10
03 X59301300049 X59301300049 2016/12/18

MTU 4000 GAS Engine Models & Specifications

MTU 2000 M96 Family

MTU 4000 GAS Engine Models & Specifications

Make Rated power kW Speed rpm Bore/stroke mm (in)
8V 4000 L64 1012 1500 170/210 (6.7/8.3)
8V 4000 L64 FNER 1013 1500 170/210 (6.7/8.3)
12V 4000 L64 1523 1500 170/210 (6.7/8.3)
12V 4000 L64 FNER 1521 1500 170/210 (6.7/8.3)
16V 4000 L64 2028 1500 170/210 (6.7/8.3)
16V 4000 L64 FNER 2028 1500 170/210 (6.7/8.3)
20V 4000 L64 2530 1500 170/210 (6.7/8.3)
20V 4000 L64 FNER 2538 1500 170/210 (6.7/8.3)
8V 4000 L32 762 1500 170/210 (6.7/8.3)
12V 4000 L32 1151 1500 170/210 (6.7/8.3)
16V 4000 L32 1542 1500 170/210 (6.7/8.3)
20V 4000 L32 1932 1500 170/210 (6.7/8.3)
12V 4000 L64 FB 2106 1500 130/150 (5.1/5.9)
8V 4000 L33 764 1500 170/210 (6.7/8.3)
12V 4000 L33 1152 1500 170/210 (6.7/8.3)
16V 4000 L33 1549 1500 170/210 (6.7/8.3)
20V 4000 L33 1924 1500 170/210 (6.7/8.3)
20V 4000 L64 FB 2547 1500 170/210 (6.7/8.3)
16V 4000 L32 ER 1560 1500 170/210 (6.7/8.3)
20V 4000 L32 ER 1948 1500 170/210 (6.7/8.3)
8V 4000 L32 1169 1500 170/210 (6.7/8.3)
8V 4000 L64 FB 1012 1500 170/210 (6.7/8.3)
16V 4000 L64 FB 2032 1500 170/210 (6.7/8.3)
